Structural Steel Pipe

Product introduction In general, structural pipe is a type of steel construction pipe that meets certain standards of chemical composition and mechanical properties. This pipe can be used for a wide variety of structural applications and there are variety of types of structural pipe available. Common types of structural pipe include:Seamless Steel Pipe: Seamless steel structural pipe is a durable pipe product that is commonly used for dock piling, pipe piling, caissons, and bollards.ERW Steel Pipe: This structural pipe is typically known to the construction industry as high quality line pipe and it is commonly used by the oil and utility companies. This steel pipe can be used for sign pole, column, dock, and tunnel construction.Spiral Steel Pipe: This is an economical and durable type of structural pipe that offers long lasting durability for things like road casing, piling and trenches.DSAW Carbon Steel Pipe: This structural pipe is welded on both the OD and the ID. It is available in many different grades and is used for road casing, road boring, culverts, and more.Fence Pipe: This is a type of structural pipe that is becoming popular for building fences because of its high durability and strength. This structural pipe is used for enclosing parks, parking lots, and more.Culvert Pipe: This type of pipe is not necessary a high quality or extremely durable structural pipe, but rather a construction pipe used for diverting water under and around driveways, water and sewer systems, drainage systems, and temporary bridges. Application: In Structural Engineering and Construction Industry Specification: OD: 1/8'' ~ 26'' (10.3 ~ 660mm) WT: SCH 10 ~ 160, SCH STD, SCH XS, SCH XXS LENGTH: Fixed Length (5.8/6/11.8/12mtr), SRL, DRL Standard: ASTM A53/A252/A500/A501, JIS G3444, EN 10210/10219 Ends: Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends Surface: Bare, Lightly Oiled, Black/Red/Yellow Painting, Zinc/Anti-corrosive Coating Packing: Bundled/In Bulk, Plastic Caps Plugged, Waterproof Paper Wrapped Detail Specification of Structural Steel Pipe API 5L/ASTM A106 GR.B, Structural Steel Pipe DN OD(mm) SCH40(6m/5.8m) SCH40(6m/5.8m) SCH40(6m/5.8m) WT WT WT (mm) (mm) (mm) 1/4'' 13.7 2.24 3.02 / 3/8'' 17.1 2.31 3.2 / 1/2'' 21.3 2.77 3.73 4.78 3/4'' 26.7 2.87 3.91 5.56 1'' 33.4 3.38 4.55 6.35 1-1/4'' 42.2 3.56 4.85 6.35 1-1/2'' 48.3 3.68 5.08 7.14 2'' 60.3 3.91 5.54 8.74 2-1/2'' 73 5.16 7.01 9.53 3'' 88.9 5.49 7.62 11.13 3-1/2'' 101.6 5.74 8.08 / 4'' 114.3 6.02 8.56 13.49 5'' 141.3 6.55 9.53 15.88 6'' 168.3 7.11 10.97 18.26 8'' 219.1 8.18 12.7 23.01 10'' 273 9.27 15.09 28.58 12'' 323.8 10.31 17.48 33.32 14'' 355.6 9.53 11.13 19.05 16'' 406.4 9.53 12.7 21.44 18'' 457 9.53 14.27 23.83 20'' 508 9.53 15.09 26.19 24'' 610 9.53 17.48 30.96 Technical data Structural Steel Pipe Chemical Composition and Mechanical Properties Standard Grade Chemical Composition (%) Mechanical Properties ASTM A53 C Si Mn P S Tensile STrength(Mpa) Yield STrength(Mpa) A ≤0.25 - ≤0.95 ≤0.05 ≤0.06 ≥330 ≥205 B ≤0.30 - ≤1.2 ≤0.05 ≤0.06 ≥415 ≥240 ASTM A106 A ≤0.30 ≥0.10 0.29-1.06 ≤0.035 ≤0.035 ≥415 ≥240 B ≤0.35 ≥0.10 0.29-1.06 ≤0.035 ≤0.035 ≥485 ≥275 ASTM A179 A179 0.06-0.18 - 0.27-0.63 ≤0.035 ≤0.035 ≥325 ≥180 ASTM A192 A192 0.06-0.18 ≤0.25 0.27-0.63 ≤0.035 ≤0.035 ≥325 ≥180 API 5L PSL1 A 0.22 - 0.90 0.030 0.030 ≥331 ≥207 B 0.28 - 1.20 0.030 0.030 ≥414 ≥241 X42 0.28 - 1.30 0.030 0.030 ≥414 ≥290 X46 0.28 - 1.40 0.030 0.030 ≥434 ≥317 X52 0.28 - 1.40 0.030 0.030 ≥455 ≥359 X56 0.28 - 1.40 0.030 0.030 ≥490 ≥386 X60 0.28 - 1.40 0.030 0.030 ≥517 ≥448 X65 0.28 - 1.40 0.030 0.030 ≥531 ≥448 X70 0.28 - 1.40 0.030 0.030 ≥565 ≥483 API 5L PSL2 B 0.24 - 1.20 0.025 0.015 ≥414 ≥241 X42 0.24 - 1.30 0.025 0.015 ≥414 ≥290 X46 0.24 - 1.40 0.025 0.015 ≥434 ≥317 X52 0.24 - 1.40 0.025 0.015 ≥455 ≥359 X56 0.24 - 1.40 0.025 0.015 ≥490 ≥386 X60 0.24 - 1.40 0.025 0.015 ≥517 ≥414 X65 0.24 - 1.40 0.025 0.015 ≥531 ≥448 X70 0.24 - 1.40 0.025 0.015 ≥565 ≥483 X80 0.24 - 1.40 0.025 0.015 ≥621 ≥552 Structural Steel Pipe Chemical Composition and Mechanical Properties Standard Grade Chemical Composition Mechanical Properties C Si Mn P S Cr Ni Cu Tensile Strength(Mpa) Yield Strength(Mpa) Elongation(%) GB/T8163 10 0.07-0.14 0.17-0.37 0.35-0.65 ≤0.035 ≤0.035 ≤0.15 ≤0.25 ≤0.25 335-457 ≥205 ≥24 20 0.17-0.24 0.17-0.37 0.35-0.65 ≤0.035 ≤0.035 ≤0.25 ≤0.25 ≤0.25 410-550 ≥245 ≥20 Q345 0.12-0.20 0.20-0.55 1.20-1.60 ≤0.045 ≤0.045 - - - 490-665 ≥325 ≥21 Structural Steel Pipe Tolerance Pipe types Pipe Szie(mm) Tolerances Hot rolled OD All ±1% (min ±0.50mm) WT All +15%, -12.5% Cold drawn OD 6～10 ±0.20mm 10～30 ±0.40mm 30～50 ±0.45mm >50 ±1% WT ≤1 ±0.15mm >1～3 +15% -10% >3 +12.5% -10% Structural Steel Pipe End Plain End Wall Thickness less than 0.5 inch, including SCH STD & SCH XS Plain End (Square Cut) Wall Thickness over 0.5 inch, including SCH XXS Beveled End Wall Thickness less than 0.5 inch, including SCH STD & SCH XS Couplings Outside Diameter equal or less than 2'' Thread Protection Outside Diameter over 4 inch
